How Javascript affects browser performance

With the move towards frontend frameworks the web is becoming increasingly loaded with javascript. It used to be that you could disable javascript and have a usable web experience but for the most part that is no longer the case. In some ways it is good that we are building websites with more functionality than ever existed in the past. But it is also a double-edged sword that requires us to craft our applications in a way that contributes to a good user experience. I’m going to talk about some of the metrics that are used to measure performance and how these metrics can be impacted by the javascript we write.

When I think of a good user experience from a performance perspective here are some of the things that come to mind for me:

• Fast loading
• Minimal pop-in or content shifting
• Fast feedback to user input (clicks, typing, scrolling, dragging, etc) with smooth and fluid motion

A tool made by Google called Lighthouse has some metrics that align pretty well with the goals listed above and that will be referenced throughout:

• Largest Contentful Paint (LCP) - Compared to the older but long-time used First Contentful Paint (FCP) which measured the time until content is first painted to the screen, LCP measures the time it takes for the largest element on the page to be painted. So similar in purpose but more relevant to the user experience as users usually care more about when the page is usable than when the first piece of content was rendered.
• Cumulative Layout Shift (CLS) - This measures the amount of layout shifts that occur when page content is loading. Content shifting can lead to a bad user experience when reading content or when attempting to interact with the website.
• Interaction to Next Paint (INP) - This is a newer metric that measures the time it takes for the browser to respond to user input. When compared to the earlier metric First Input Delay (FID) which measured the time until the first event handler was called, INP measures the time until the next frame is painted after an event handler is called. It is a more accurate round trip assessment of the feedback loop between the user and the browser.

Most of these metrics can be impacted by the network requests and backend performance, but here we are going to focus on the impact that our javascript code can have.

Javascript in the browser

One of the most important things to understand about how javascript works in the browser is that it is single-threaded. This means that only one piece of javascript (excluding web workers) can run at a time. This is important to keep in mind when considering the metrics above, especially in this age of single-page apps, as your frontend code has a distinct impact on all of them.

It’s worth noting that your code is not just competing with other javascript code (including third-party code), but it’s also competing with the browser itself. If you are doing a lot of work it can impact the browser’s ability to do its own work such as responding to user input and rendering. An example of this can be seen below:

Above this demo you can see a graph that is refreshing every second to show how many frames per second the browser is rendering. We have two buttons that, when clicked, simulate executing some work in javascript that updates your application (specifically using React in this case). The first button, work(), executes a loop that counts up to 3000 milliseconds and updates a text field with the value during each iteration.

const [time, setTime] = useState(0);

function work() {
  const start = Date.now();
  while (Date.now() - start < 3000) {
    setTime(Date.now() - start);
  }
}

function doSetTimeoutWork() {
  const start = Date.now();
  function workChunk() {
    const elapsed = Date.now() - start;
    setTime(elapsed);
    if (elapsed < 3000) {
      setTimeout(workChunk, 0);
    }
  }
  workChunk();
}

// jsx
<TextField label="Time" value={time} />

<Button variant="contained" onClick={work}>
  work();
</Button>
<Button variant="contained" onClick={doSetTimeoutWork}>
  doSetTimeoutWork();
</Button>

Do you notice what happens when you click the button?

• The click handler executes our work() function
• As the handler is executing the main browser thread is blocked
• setTime (through React) batches updates to the text field but the browser is unable to render the updates until the thread is unblocked

This highlights two ways how our frontend code can impact our metrics:

1. The long round-trip time between when the button was clicked and when the text field updates results in a poor user experience as shown by a poor INP score.
2. In a single-page app our code may be responsible for rendering the contents of the page which means long-running code at load can impact us two-fold by both slowing our apps ability to generate content and slowing the browser’s ability to paint the content to the page. This could be indicated by a poor LCP score.

The obvious solution is to do less work especially during the initial page load. But for the work we need to do we can break that work up into smaller chunks that allow for the browser to still perform its functions. The second button, doSetTimeoutWork, highlights this strategy by using setTimeout to break the continuing work out into tasks that are scheduled to run as part of the event loop. Both of these handlers are executing for roughly the same amount of time, but one is doing it in a way that allows the browser to also do its work.

Let’s look at another example, this one breaks the work into smaller chunks as suggested above but these chunks are designed to run with each frame and block for a certain amount of time in order to simulate a poor frame rate. Try dragging the box below, then click work(), then try dragging the box again. See how the experience changes:

const TARGET_FPS = 10;
const targetFrameDuration = 1000 / TARGET_FPS;
const blockDuration = targetFrameDuration * 0.9;
function noop() {}
function chunk() {
  if (!simulationActiveRef.current) {
    return;
  }
  const blockStart = performance.now();
  while (performance.now() - blockStart < blockDuration) {
    noop();
  }
  animationFrameIdRef.current = requestAnimationFrame(chunk);
}
function work() {
  if (simulationActiveRef.current) {
    simulationActiveRef.current = false;
    setIsActive(false);
    if (animationFrameIdRef.current) {
      cancelAnimationFrame(animationFrameIdRef.current);
      animationFrameIdRef.current = null;
    }
  } else {
    simulationActiveRef.current = true;
    setIsActive(true);
    animationFrameIdRef.current = requestAnimationFrame(chunk);
  }
}

We can see that when the frame rate drops significantly so does our ability to interact with the page. This means it’s not just a matter of letting the browser do its work, but allowing it to do its work in a consistent and timely manner. Interestingly this is an area where the lighthouse metrics might not indicate a serious problem, but the user experience definitely will…

The pixel pipeline

If you were really attentive while “simulating work” you may have noticed that page scrolling seems mostly unaffected by our lowered framerate. This article provides a hint of why that is the case.

In this diagram (that I shamelessly copied from the article) we can see the operations that the browser performs when rendering to the page. Not all of these operations necessarily need to do work when creating a frame, it depends on how and what kind of work is being done. For example, if we can avoid making changes to a DOM element’s height or width, we may be able to avoid doing expensive layout calculations. In addition, using absolute positioning of elements can also avoid layouts and improve performance (this is part of the magic behind libraries that implement virtualized scrolling).

Some of the browser’s operation, such as those that happen in the composite layer, don’t even need to work in the same thread. If we can restrict certain work to happen in composite layer we may be able to avoid having work that is competing with the browser’s javascript thread and all the other things that are happening on the page.

Coming back to the scrolling behavior above: most browsers are able to perform scrolling as part of the composite layer on a separate thread which allows for a seemingly responsive scrolling page even when the page is mostly unrespoonsive!

Below I have an example of a component that is doing work in javascript in order to update a progress bar. In one case, doAnimationFrameWork(), it is using requestAnimationFrame in order to schedule javascript work that will update the progress bar with each frame. In the other case, doCssTransition(), it is setting a css transition property onto the element which is allowing the browser to handle the animation.

function doAnimationFrameWork() {
  const start = Date.now();
  function update() {
    const elapsed = Date.now() - start;
    if (elapsed < 3000) {
      setProgress((elapsed / 3000) * 100);
      requestAnimationFrame(update);
    } else {
      setProgress(100);
    }
  }
  update();
}

function doCssTransition() {
  setCssTransition(true);
  setProgress(100);
}

// jsx
<LinearProgress
  variant="determinate"
  value={progress}
  sx={
    !cssTransition
      ? {
          "& .MuiLinearProgress-bar": {
            transition: "none",
          },
        }
      : {
          "& .MuiLinearProgress-bar": {
            transitionDuration: "3s",
          },
        }
  }
/>;

Try each and see what it looks like. Then click work() and try both again and see how the experience changes. Doing work in the composite layer while skipping the layout and paint layers is one way to improve the performance of our page.

It’s important to note that this CSS animation is possible since the progress bar is loading a known amount. The same would be true if we were using a loader to represent an indeterminate state when signaling loading. In other cases we may require javascript to update the progress bar, such as if it’s displaying actual real-time feedback of an event. It’s worthwhile considering what the best approach is for our use cases and whether we can have the browser do some work for us.

One last thing to consider is when and how many updates we are making to the DOM. We can consider what DOM operations we’re doing and how they will affect the pixel pipeline’s performance; but we can also leverage frontend frameworks to do some things for us such as batching updates to the DOM to avoid unnecessary browser renders and free us from the tedium of manually editing the DOM.

Layout shifts

Layout shifts are when the browser changes the layout of the page after it has been painted. This can happen for a number of reasons, but one of the most common ones (and the one we will concern ourselves with in this article) is when content is added to the page asynchronously by javascript. The first solution you should look at is rendering as much as you can before first paint, e.g. server or static rendering, but let’s explore after first paint.

In the following example we have a series of cards that are being loaded into the page as part of a pagination component. The cards have been simulated to load with latency as if it were coming from a backend server. They’ve also been simulated to load the word definitions themselves separately as part of a request waterfall to simulate a common scenario where all the data is not immediately available in the initial request.

As you click through the pages you can see how this affects the user experience. The pagination’s page bar itself moves as the content loads, the action buttons on the cards shift… maybe even as the user may be attempting to click them. By default there’s no indication to the user that content is even loading. Overall it’s not a pleasant experience.

The most obvious solution in this case is to reserve space for the loading content. You can toggle the Fixed Height switch to see how this improves interacting with the pagination’s page bar.

You could also remove the request waterfall by pulling up the data needed so it’s available in the original pagination request. This improves both the content shift and the load times (although as a frontend engineer this can sometimes be out of your control). You can toggle No Waterfall to see how this improves things.

You can also use skeleton’s (toggle Skeletons switch) if you want to prevent some layout shift as well as provide some visual feedback to the user that data is loading.

Some frameworks, such as React and Vue, support a newish component called <Suspense> that allow for more graceful handling of loading states, especially if you have nested components each of which may be loading their own data. Suspense allows you to delegate control of loading states up the component tree similar to how Error Boundaries work.

You change the Loading Strategy to use w/ Suspense (in this case use is referencing the new use hook in React 19) you can see examples of how the loading behaves differently when wrapping different areas of the tree such as: the whole list, the individual cards, the card body, or none/all of the above!

Performance Tradeoffs

One thing you may notice is that these performance metrics are sometimes at odds with each other and the user experience as a whole.

At a previous job (two previous jobs to be precise) I worked as an architect on a popular open-source project called Prebid.js. This library is used by publishers to monetize their websites through advertising in a process called header bidding, “header” in this case referring to the HTML <head> of a document and “bidding” referring to the live auction that occurs as soon as the page starts loading.

It was often requested that Prebid.js yield the main thread to improve FCP or IMP, and while these are worthy goals they were usually focused on a improving a single metric without considering the overall user experience. Perhaps part of the problem is metrics such as Cumulative Layout Shift didn’t exist until 2020 and initial page has always been everything. It’s always important to consider these metrics together as a whole… and maybe even metrics that are not part of the Lighthouse rubric but are important to you and your users.

Ultimately I always thought the best direction for Prebid.js would be to reduce the amount of work it does, improving LCP and INP while also being responsible with its time in a way that would reduce CLS as well.

Another example of considering tradeoffs is this site itself. You may have noticed I use custom web fonts. My performance scores in Lighthouse have always been penalized due to loading the fonts in the head and purposefully blocking rendering until they’re loaded. This choice was made to avoid Flash of Unstyled Text (FOUT). I could always just remove the fonts entirely, but I think they improve the user experience and readability… This creates a tradeoff where this site may load slightly slower on first visit to have, in my opinion, a better overall user experience.

Always consider these performance metrics as a whole and remember: user experience comes first!
